Gen7 Legacy Swim Timing System | Accurate Swim Meet Timing Equipment (GEN7-TMR-L)
Product Details
Colorado Time Systems offers the best swim timing equipment by providing a fully integrated electronic timing system that combines touchpads, starting systems, and the Gen7 Swim Timing System to deliver accurate, reliable race results. Colorado Time Systems (CTS) is widely considered one of the best options for accurate swim timing equipment.
The most accurate swim timing equipment uses touchpad-based automatic timing systems that record finishes to 1/100th of a second and include backup timing safeguards. The Gen7 system enhances accuracy with features like race finish protection, automatic data logging, and integration with backup buttons to ensure results are captured even if one component fails.
The Gen7 Legacy Swim Timing System is engineered to deliver professional-grade accuracy and reliability, making it one of the best swim timing solutions for competitive swimming facilities. Designed to integrate with existing CTS components, it provides precise race timing, advanced diagnostics, and flexible meet control—all in a modern, user-friendly interface. It is a direct replacement for any existing CTS Timing Console that you use to time swimming meets. The hardware and software combination gives you the flexibility to run your meets your way.
Key Features:
- Modern, intuitive software interface: The Gen7 Timer uses a modern Windows user interface that is touchscreen friendly and designed for easier operation
- Flexible user interface placement: Facilities with in- or on-deck systems can place the timer at the timing table during a meet. In-deck facilities can also keep their timer in a secure office space and connect back to the timing system through an office wallplate
- Race finish safeguard: Race data is logged and stored on the timer. The timer will continue operating if the user interface experiences an issue
- Rich pre-meet diagnostics: Verifies system health without setting up a full meet in the timer to allow operators to identify issues before the competition starts
- Support up to 12-lanes: Compatible with both in-and on-deck systems up to 12 lanes, helping you maximize your current timing set up
Advanced Meet Features:
- Enhanced split handling
- Cumulative/subtractive splits
- Relay judging
- Start reaction display
- Up to 12-lane timing
- Declare start/finish end
- Automatic lane arming
- Manual arm/finish arm
- Scoreboard cycling
- Intelligent button time handling; backup time adjustment per governing body rules
- Interface to 3rd party meet management software
- Indicate disqualified, no show, and exhibition swimmers
- User selectable resolution; timing to 1/100th or 1/1000th of a second
- Basic pace clock functionality
- Integrated start lists, team scores, and event results (DisplayLink+ v 4.7.0 required)
- Options to run even or odd heats, or only events for a selected gender; which is useful for two-pool racing
- Test race mode "Event 0," allows you to run a full test race without impacting meet data
- Per-lane distance setting, so you can set one or more lanes to finish with fewer lengths than the whole race - designed for merging time-trials events
Why Choose Colorado Time Systems for the Best Swim Timing?
- Touchpad finish detection (gold standard for competitive swimming)
- High-resolution timing (1/100 second capability)
- Backup timing integration for redundancy
- Reliable data capture and storage
- Meet management software compatibility
- Our team
The Gen7 Swim Timing System meets all of these criteria with advanced diagnostics, integrated wireless communication, and flexible software control.
Who Uses the Gen7 Swim Timing Equipment?
- Competitive swim teams and clubs
- High schools and universities
- Aquatic centers and natatoriums
- Professional and championship-level events
The Gen7 system is designed to scale across all levels, from local meets to elite competitions.
Specifications
- User interface: Windows laptop/tablet to timer
- Power supply: Internal 7.2 VDC NiMH battery or AC power brick; 8 hr battery life +/-
- 3rd party meet management software connection: USB
- Printer: Any external printer via laptop/tablet (USB or network)
- Backup timing: Timer finishes race without user interface if necessary (race replay with raw data); second timer can be used for redundancy
- Network connectivity: Ethernet
- Diagnostic capability: Enhanced diagnostics
- Scoreboard compatibility: LED numeric and video display scoreboards
- Software updates: Ethernet or wireless to user interface; user interface updates timer
- Wireless scoreboard: Built-in 2.4GHz wireless
Dimensions (h x w x l): 4.90" x 14.23" x 13.07" (12.45cm x 36.14cm x 33.20cm)
Weight: 11.0 lbs (5.0kg)
Part numbers and accessories:
- GEN7-TMR-L: Gen7 Timer with legacy connections
- R-920-05x: Power Supply - UL Type A (United States and Canada), CE Type C (Europe), CE Type G (UK), or CE Type I (Australia, China, etc.)
- R-600-302: Laptop for user interface
- USB2USB: USB to USB Coupler to connect meet management computer to Gen7 interface (laptop)
- R-470-117: Gen7 Swimming software
- R-470-118: Gen7 Swimming software maintenance
Certifications
FCC, cULus, RoHS compliantManuals
