Colorado Time Systems Gen7 Diving software and hardware are designed to allow you to run flawless, lightning fast meets. While in use at high-level meets such as USA Diving Winter Nationals, UANA Puerto Rico Grand Prix, USA Diving Synchronized National Championships, Big 10 Championships, NCAA Championships, and more; people are saying, “The amount of data on the dive and diver makes it so easy to use,” and “Changes in dives or scoring issues are so easy to handle, which keeps the event much closer to the time lines.”
Gen 7 Diving allows pre-meet and “on the fly” data entry and storage, meet management software information upload and download from a PC. Gen7 Diving is fully compatible with DiveMeets®, ieDive, OmadaTrak, and other diving meet management programs.
The diving software supports individual and synchronized scoring, and is operable with either Gen7 diving judging terminals or manual input of flash card scores. Software features a modern, intuitive interface and work flow, and is optimized for touch screens. Gen7 diving software supports World Aquatic (including mixed synchro), USA Diving, NCAA, and High School (including CIF 1m/3m Springboard) rules.
Gen7 diving judging terminals allow your judges to focus on the dive and provide their scoring data with minimal effort. Each diving judging terminal features a sealed keyboard with a backlit LCD display suitable for indoor and outdoor sunlight readability.
The rugged locking communications cable that connects each judging terminal to the diving interface box provides peace of mind that no connections will inadvertently come loose during the meet.
Judging terminals display:
- Diver’s name
- Diver’s team or country name
- Other judges’ scores, once finalized
- Dive
- Dive D.D.
- Specific terminal number
Judging terminals include a “request change” button to notify the operator if they need to request permission to correct their submitted score.
Both World Aquatics and USA Diving request that elite-level events utilize a wired diving judging system.
Read about USA Diving using GEN7 Diving Equipment in our Event Blog; The 2023 USA Diving National Championships to use GEN7 Diving at the Mylan Park Aquatic Center
Specifications
Gen7 Diving Packages
| Part Number | # of Judges | Synchronized Events | Simultaneous Events |
| JSYS-3 | 3 | N | N |
| JSYS-5 | 5 | N | N |
| JSYS-7 | 7 | N | N |
| JSYS-11 | 11 | Y | N |
| JSYS-15 | 15 | Y | Y |
Manuals
| Name | Download |
|---|---|
| Gen7 Diving F1022 | Download |
Videos
Software downloads
Gen7 Diving v1.5.1 - 24 October 2025
Release Notes:
-
[FIXED] IH-01 and JT-01 firmware updates are being labelled with incorrect version
-
[NEW] Create combined events (e.g., Boys 1m and Girls 3m) without assistance from Meet Management software
-
Reports have been updated to group by sub-event
-
-
[NEW] Added enhanced features for High School events
-
Dive Sheet rules checking
-
Configurable cuts for semis and finals
-
Printed Dive Sheets match NFHS template
-
-
[NEW] Keyboard entry of judges’ awards
-
[NEW] Added ability to print dive sheets with awards and calculations filled in
-
[NEW] Added additional name formatting options for reports and leaderboard
-
[NEW] Added option to send Start List to Leaderboard at the start of an event
-
[NEW] Added import/export functionality for myIHSAA users (Indiana High Schools)
-
[IMPROVED] More informative update notifications (with release notes)
-
[IMPROVED] Redesigned dropdown button graphics to better indicate the presence of a dropdown menu (e.g., Clear Scoreboard, Export)
-
[IMPROVED] On the Run Event screen, large messages now appear to indicate “Judges Call” or “Waiting Mode”
-
[IMPROVED] Judges’ change requests are automatically granted if all awards have not yet been received
-
[IMPROVED] On the Run Event screen, the judge’s award out of range indicator (purple background) now takes Synchro judging groups into account
-
[IMPROVED] During combined events, scoreboard event name and total number of rounds now reflects the correct “sub-event”
-
[IMPROVED] Scoreboard outputs will automatically blank when exiting the software
-
[IMPROVED] Layout and verbiage in Scoreboard settings is now more informative
-
[IMPROVED] reworked timeout mechanism in Meet Management receive routines to allow for larger events
-
[IMPROVED] Device listing for Meet Management Connection and Additional Scoreboards now display COM Port number for CTS USB Connect Devices
-
[IMPROVED] Removed “Dive B” from Mixed Synchro entry
-
[IMPROVED] Dak RTD output now regularly retransmits (previously transmissions on happened when data was changed)
-
[FIXED] Help overlay was not functioning properly
-
[FIXED] Judges’ Call mode was not functional on Judges Terminals
-
[FIXED] When changing the displayed ordering of the divers list in the Event Operations screen, sort by name would not sort correctly
-
[FIXED] When cutting/scratching a diver from the Event Operations screen, the “Cut After Round” data field was not getting populated correctly in reports
-
[FIXED] After cutting/scratching a diver from the Event Operations screen, if “Consolidate Any Gaps” was chosen, the event could reorder completely
-
[FIXED] Synchro Judge labels were incorrect (read S7, not S1)
-
[FIXED] Clicking “Reset Dive” would cause the next set of awards to not be received
-
[FIXED] Clicking “Clear Scoreboard” did not clear Judges’ Awards
-
[FIXED] Software would crash if receiving Synchro data from Meet Management software if the names were not formatted correctly
-
[FIXED] Scoreboard Intensity changes were not correctly propagating to LED-R scoreboards
-
[FIXED] Special Characters were not displaying correctly on LED-R scoreboards
- fixed issue with Judges Call information not transmitting to JT-01s
- fixed issues with special character translation on RS-232 output
- fixed issues with intensity commands on RS-232 output
-
fixed issues with keypad crosstalk (e.g., pressing 8 and getting a 7)
NOTE: If update from a version prior to v1.2.2, there is a mandatory firmware update for all Judges' Terminals (JT-01) and Interface Hubs (IH-01)
